Applications:

Conduit bodies connect and allow for changes in the direction of conduit runs. Can be used as pulling fittings. Accessible wiring chamber provides a spacious location to make splices.

Features:

• Surface: Polished with standard smooth and bright finish to increase corrosion resistance and aesthetic appearance, or Mirror surface
• Manufactured in type 316 or 304 stainless steel for increased corrosion resistance
• Solid stainless construction permits easy installation using ordinary hand tools
• The flat back design allows extra wiring capacity
• Cover and Gasket set included
• Gasket color: black for industry, or white neoprene FDA Approved
• Use of Phillips head screws, or hex head cap screws helps prevent any harboring points
• Marking: Laser marking

Brands Available:

• Yeallion, or OEM

Certifications and Compliances:

• UL Listed
• NSF/ANSI 169 Certificated
• 2300 / FDA approved neoprene gasket
• Intended for installation in accordance with Article 314 of ANSI/NFPA 70, National Electrical Code(NEC)
• Approved for wet locations, IP69 Rated

Material:

• Body: 316SS or 304SS
• Gasket: black or white neoprene FDA Approved
• Cover and Screw: 316SS or 304SS
